Product Details
Drag to rotate • Scroll to zoom
Multi Gas Analyzer Detecting
in Zone 1
*
High-precision multi-gas analyzer for hydrogen, methane, and CO₂ detection in ATEX Zone 1 hazardous areas. Designed for refinery process control and pipeline injection monitoring.
Scroll to explore
Multi Gas Analyzer Detecting in Zone 1 delivers Process Control* grade precision
Fast hydrogen detection with high sensitivity
Low power consumption, suitable for embedded systems
Wide operating hydrogen concentration range (and humidity range)
High selectivity against common interfering gases (CH₄, CO₂)
Compact, robust package for industrial environments
Compatible with external digital or analog readout electronics
High-precision multi-gas analyzer for hydrogen, methane, and CO₂ detection in ATEX Zone 1 hazardous areas. Designed for refinery process control and pipeline injection monitoring.
Fast hydrogen detection with high sensitivity
Technical Specifications
Target Gas
Target Gas
Hydrogen (H₂), Methane (CH₄), Carbon Dioxide (CO₂)
Detection Range
Detection Range
Typical: 0.1 – 99.9 % vol H₂ (We have available wider ranges, contact Fast Sense for other models)
Repeatability
< 0.1 %
Auxiliary sensors
Auxiliary Sensors
Temperature & Humidity sensor
Sensitivity
Resolution
0.05% of the reading
Response Time (T90)
< 30 sec (projected < 3 s)
Environmental Specifications
Operating Temperature
0 °C to +80 °C
Storage Temperature
-20 °C to +85 °C
Operating Humidity
Up to 95% RH, non-condensing
Pressure
Atmospheric pressure (<100 mbar)
Electrical Characteristics
Supply power (Solenoid)
12-28 V (recommended 24 V)
Supply power (4-20mA)
12-28 V (recommended 24 V)
Supply power (Equipment)
12-15 V (recommended 12 V)
Supply power (Mudbus)
12-28 V (recommended 24 V)
Power Consumption
Average
< 0.6 W
Peak
< 1.2 W
Fast hydrogen detection with high sensitivity
Low power consumption, suitable for embedded systems
Wide operating hydrogen concentration range (and humidity range)
High selectivity against common interfering gases (CH₄, CO₂)
Compact, robust package for industrial environments
Compatible with external digital or analog readout electronics
Engineered for precision
*Built from deep research and field expertise to deliver the accuracy and reliability your operations demand.
ANALYZER Technology
Designed for Process Control*, Pipeline Injection, Electrolyzers applications. Delivering reliable performance even in the most demanding environments.
System Configuration
Select your required specifications to configure this production unit
High-precision multi-gas analyzer for hydrogen, methane, and CO₂ detection in ATEX Zone 1 hazardous areas. Designed for refinery process control and pipeline injection monitoring.
